MAINTENANCE
87
3. Fill the drive unit through the fill/drain hole with Torco MTF
Gear Oil until an air‑free stream of lubricant flows from the
gear oil level hole of gear housing.
a - Top vent screw
b - Fill/drain screw
Tube Ref
No.
Description Where Used Part No.
150
Torco MTF Gear Oil
VI Drive gear
housing
92-849684 1
IMPORTANT: If the filter was replaced, rotate the propeller shaft
at least 80 full revolutions to fill the filter cavity with oil. Recheck
the fluid level and add fluid as necessary.
4. Install vent screw and washer and remove tube from fill/drain
hole. Quickly install the sealing washer and the fill/drain
screw. Tighten securely.
5. Check oil level after first test trial. Add fluid if necessary.
CHANGING TRANSOM INPUT SHAFT BEARING HOUSING
GEAR LUBE (DRIVE-LINE MODELS)
1. Remove the drain plug and drain the oil.
2. Install the drain plug and tighten securely.
3. Remove the plug from the fill hole.
To Next Page
