MAINTENANCE
90
IMPORTANT: Propeller damage can occur if there is not enough
space between the propeller tips. Multi‑engine configurations
require a minimum distance of 25.4 mm (1 in.) gap between
propeller tips to prevent damage to the propellers and other
equipment.
a
c
d
e
f
21685
b
a - Nylon Nut
b - Jam nut
c - Washer
d - Adaptor (Mercury Racing
sterndrive cleaver
propeller)
e - Bushing
f - Retaining ring
1. Install the adaptor into the propeller, as shown.
