Mercury MERCRUISER - Multi-Point Drain (MPD) System; Three Point Manual Drain System

Section 6 - Storage
90-864197076 NOVEMBER 2008 Page 105
Three Point Manual Drain System
a - Blue drain plug
Multi-Point Drain (MPD) System
a - Side of cylinder block
b - Bottom of exhaust
manifolds
33155
Fuel cooler to thermostat housing
a - Check valve (if equipped)
a
a
6126
10226
M110050
93235672
b
a
a
b
6129
a
6131
