Section 5 - Maintenance
90-899883295 JUNE 2008 Page 89
Tube Ref No. Description Where Used Part No.
87
High Performance Gear
Lubricant
Gear lube monitor 92-858064K01
3. Replace the cap.
NOTE: When filling the entire sterndrive unit refer to Changing instructions, following.
Changing
1. Remove the gear lube monitor from the bracket.
a
8530
a - Gear lube monitor
2. Empty the contents into a suitable container.
3. Install the gear lube monitor in the bracket.
4. Bravo One Models: Remove the propeller, lower the sterndrive unit to the full down/
in position, remove the oil fill/drain screw and sealing washer and drain the oil.
a
mc79506-1
b
a - Oil fill/drain screw
b - Sealing washer
To Next Page
