Mercury Optimax 135 Service Manual

POWERHEAD
90-855347R1 JANUARY 1999 Page 4A-53
Throttle Lever and Shift Shaft
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm.
1 1 THROTTLE CONTROL LEVER
2 1 SCREW (.375-16 x 1-3/4 IN.)
240 20 27
3 1 BUSHING
4 1 WASHER
5 1 WASHER
6 1 SCREW (2-1/8 IN.)
7 1 NUT (1/4-20)
8 1 CAP
9 1 INSERT
10 1 WASHER
11 1 NUT
50 5.5
12 1 CAM
13 1 BUSHING
14 1 SCREW (M6 x 40)
45 5
15 2 SWIVEL BUSHING
16 1 THREADED BALL Drive Tight
17 1 LINK
18 1 ROLLER
19 1 THROTTLE ROLLER
20 1 SCREW (M5 x 16)
Drive Tight
21 1 WASHER
22 1 STAR WASHER
23 1 ANCHOR BRACKET
24 1 LATCH
25 2 SCREW-Drive
26 1 CAP
27 1 WEAR PLATE
28 1 LATCH
29 1 WASHER
30 1 NUT
31 3 SCREW (.312-18 x 7/8)
160 18
32 1 GUIDE BLOCK
33 1 SPRING
34 1 LINK ROD ASSEMBLY
35 1 SHIFT SHAFT ASSEMBLY
36 1 ROLL PIN
37 1 SHIFT SHAFT LEVER–UPPER
38 1 BUSHING
39 1 WAVE WASHER
40 1 WASHER
41 1 NUT
42 1 IDLE STABILIZING SHIFT KIT
43 2 SCREW (6-32)
15 1.7
44 2 WASHER

Mercury Optimax 135 Specifications

General

Engine Type	V6
Horsepower	135 HP
Fuel Induction System	2-stage direct fuel injection
Full Throttle RPM Range	5000-5750 RPM
Alternator Output	60 amp / 756 watt
Starting System	Electric
Steering	Remote
Dry Weight	431 lbs
Shaft Length	20", 25"
