Mercury Optimax 135 Service Manual

RIGHT HAND NON-RATCHETING
90-855347R1 JANUARY 1999 Page 6A-7
Gear Housing (Drive Shaft)(Standard Rotation)
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm.
1 1 GEAR HOUSING (BLACK)(BASIC)
2 1 CONNECTOR ASSEMBLY 50 5.5
3 2 DOWEL PIN
4
1 STUD (3-1/8 IN.) (LONG)
4
1 STUD (3-11/16 IN.) (X-LONG)
5 2 STUD (2-1/16 IN.)
6 1 STUD (3-3/8 IN.)
7 2 STUD (3-1/8 IN.)
8 1 FILLER BLOCK
9 1 ROLLER BEARING
10 2 ANODE
11 1 SCREW (M6 x 40)
12 1 NUT 60 7
13
1 PINION GEAR (1.87:1 - 15 TEETH)(150)(Part of 43-828174A2)
13
1 PINION GEAR (2:1 - 14 TEETH)(135)(Also part of 43-828176A2)
14 1 WASHER
15 1 NUT 75 101
16 AR SHIM SET
17 1 SCREW–drain (MAGNETIC) 60 7
18 1 SCREW–grease filler 60 7
19 2 WASHER
20 1 STA-STRAP
21 1 SHIFT SHAFT
22 1 O-RING
23 1 BUSHING ASSEMBLY 50 5.5
24 1 OIL SEAL
25 1 WASHER–rubber
26
1 DRIVE SHAFT (LONG)
26
1 DRIVE SHAFT (X-LONG)
27 1 ROLLER BEARING
28 1 CUP
29 1 RETAINER 100 135
30
1
WATER PUMP BASE
31 1 RETAINER
32 1 GASKET
33 1 O-RING
34 1 OIL SEAL
35 1 OIL SEAL
36 1 GASKET–lower
37 1 GASKET–upper
38 1 FACE PLATE
39 1 WATER PUMP BODY ASSEMBLY
40 1 INSERT
41 1 SEAL–rubber
42 1 lMPELLER
43 1 KEY
44 1 SCREW (#14-8 x 2-1/4 IN.) 35 4
45 2 WASHER
46 2 NUT 50 68
47 1 WASHER
48 1 NUT 50 68
49 1 SLEEVE

Mercury Optimax 135 Specifications

General

Engine Type	V6
Horsepower	135 HP
Fuel Induction System	2-stage direct fuel injection
Full Throttle RPM Range	5000-5750 RPM
Alternator Output	60 amp / 756 watt
Starting System	Electric
Steering	Remote
Dry Weight	431 lbs
Shaft Length	20", 25"
