39
Chapter 4 Congure the Router in Wireless Router Mode
1 ) Enable Time Limits on Monday to Friday and Saturday & Sunday then set the
allowed online time to 2 hours each day.
2 ) Enable Bed Time on School Nights (Sun to Thur) and use the up/down arrows or
enter times in the fields. Devices under this profile will be unable to access the
internet during this time period.
3 ) Click SAVE.
Note: The effective time limits are based on the time of the router. You can go to Advanced > System > Time to modify
the time.
Done!
The amount of time your child spends online is controlled and inappropriate content is
blocked on their devices.
4. 6. QoS
QoS (Quality of Service) is designed to ensure the efficient operation of the network when
come across network overload or congestion. Devices set as high priority will be allocated
more bandwidth and so continue to run smoothly even when there are many devices
connected to the network.
I want to:
Ensure a fast connection of my computer while I play online games for the next 2 hours.
How can I do that
1. Visit http://mwlogin.net, and log in with the password you set for the router.
2. Go to Advanced > QoS.
3. Tick the Enable checkbox of QoS.
4. Enter the maximum upload and download bandwidths provided by your internet service
provider, and then click SAVE. 1Mbps equals to 1,000Kbps.
5. Find your computer in the Device Priority section and toggle on Priority. Select 4 hours
from the drop-down list of Timing. Your computer will be prioritized for the next 4 hours.

Other manuals for Mercusys MR30G

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Mercusys MR30G and is the answer not in the manual?

Mercusys MR30G Specifications

General IconGeneral
DSL WANNo
Ethernet WANYes
WAN connection typeRJ-45
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)1167 Mbit/s
WLAN data transfer rate (first band)300 Mbit/s
WLAN data transfer rate (second band)867 Mbit/s
Antennas quantity4
Antenna gain level (max)5 dBi
Cabling technology10/100/1000Base-T(X)
Receiver sensitivity11g 6Mbps: -96dBm 11g 54Mbps: -78dBm 11n HT40 MCS7: -74dBm 11n HT20 MCS7: -71dBm 11a 6Mbps: -97dBm 11a 54Mbps: -79dBm 11ac VHT20 MCS8: -74dBm 11ac VHT40 MCS9: -70dBm 11ac VHT80 MCS9: -65dBm
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
Firewall securitySPI Firewall, IP/MAC Address Binding
NAT functionalityPort Forwarding, Port Triggering, UPnP, DMZ
Security algorithmsWPA-PSK, WPA2-PSK
Supported network protocolsPPPoE/L2TP/PPTP
Cables includedLAN (RJ-45)
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 90 %
Power source typeAC
Ethernet LAN (RJ-45) ports3
Package typeBox
Product typeTabletop router
Product colorBlack
LED indicatorsStatus
Weight and Dimensions IconWeight and Dimensions
Depth125.9 mm
Width159.7 mm
Height37.1 mm
