Metapace S-2 Hardware Manual
2.6 USB HID VIA THE CRADLE
For USB HID, use the USB cable to connect the scanner via the cradle to the USB port of
PC and connect the power supply cord if necessary. Run any text editor on your
computer, and the scanned data will be transmitted to the computer.
HID Settings
Defaults
Keyboard Type PCAT (US)
Digits Layout Normal
Capital Lock Type Normal
Capital Lock State Off
Alphabets Transmission Case-sensitive
Digits Transmission Alphanumeric keypad
Inter-Function Delay 0 (ms)
Send “NR” to Host Disable
2.6.1 ACTIVATE USB HID & SELECT KEYBOARD TYPE
When USB HID interface is activated, you will have to select a keyboard type to complete
this setting.
1) Read the label above to activate USB HID and select a keyboard type.
2) Read the “
Decimal Value” label on page 195. Refer to the table below for the number
of desired keyboard type.
3) Read the “Validate” label on the same page to complete this setting.
Activate USB HID & Select Keyboard Type …
