Metra Electronics 95-8202 - Scion XA 2004-2006 Dash Disassembly; Scion XB 2004-2007 Dash Disassembly

12
Dash Disassembly 95-8202
Scion XA 2004-2006
(Figure B)
(Figure A)
(Figure D)
(Figure C)
1. Pulloutwardonthe(3)
climatecontrolknobsand
remove.(FigureA)
2. Remove(2)Phillipsscrews
frombehindtheoutertwo
climateknobs.(FigureB)
3. Unsnapandremovethe
trimpiecesoneachsideof
theclimatecontrol/ashtray/
pocketassembly.(FigureC)
4. Remove(2)Phillipsscrews
fromthebottomofthe
climatecontrol/radiotrim
panelandunsnapand
removetheentirepanel.
(FigureD)
5. Remove(4)Phillipsscrews
toremovethefactoryradio.
6. Removefactorybrackets
fromradio.Retainbrackets
foruseduringkitassembly.
 Continue to kit assembly
1. Pulloutwardonthe(3)climatecontrolknobsand
remove.(FigureA)
2. Remove(2)Phillipsscrewsfrombehindtheouter(2)
knobs.(FigureB)
3. Unsnapandremovetheentirepanelsurroundingthe
climatecontrolsandtheradio.(FigureC)
4. Remove(4)Phillipsscrewstoremovethe
factoryradio.
5. Removefactorybracketsfromradio.Retainbrackets
foruseduringkitassembly.
 Continue to kit assembly
Scion XB 2004-2007
(Figure A) (Figure B)
