Dash Disassembly 95-8202
7. Remove(1)10mmboltbeneath
climatecontrolbehindpocket
door.Unsnapandremoveclimate
control.(FigureC)
8. Remove(2)10mmboltsbeneath
radiobehindclimatecontrols.
9. Unsnapandremoveentirecenter
panelaroundradio.(FigureD)
10.Remove(2)10mmbolts
securingradio.
11.Unplugandremoveradio.
12.Removefactorybracketsfrom
radio.Retainbracketsforuse
duringkitassembly.
 Continue to kit assembly
(Figure C)
Toyota 4 Runner 2003-2009 (excluding Limited)
(Figure B)
1. Removethe(3)climatecontrol
knobsbypullingstraightoutward.
(FigureA)
2. Remove(3)Phillipsscrewsfrom
behindknobs.(FigureA))
3. Positionventsfacingupwardand
remove(1)Phillipsscrewfrom
eachA/Cvent.(FigureB)
 Continued on next page
(Figure B)
Toyota Tundra 2003-2006
(Figure A)
