Metra Electronics 95-8202 - Toyota Matrix 2009-2010 (with factory navigation) Dash Disassembly; Toyota 4 Runner 2003-2009 (excluding Limited) Dash Disassembly

6
Dash Disassembly 95-8202
1. Unclipandremovetheradiotrim
panelincludingtheA/Cvent.
(FigureA)
2. Remove(4)10mmboltssecuring
thefactoryradio.Unplugand
removetheradio.(FigureB)
 Continue to kit assembly
Toyota Matrix 2009-2010 (with factory navigation)
1. Unsnapandremovetrimfrom
aroundshifter.
2. Unsnapandremovetrimcovers
fromaroundcenterconsolepocket
edgeatfrontandrearofconsole.
3. Unsnapandremovecenterconsole
cover.(FigureA)
4. Unsnaptrimringfromaround
ignitionkeycylinder.
5. Remove(1)10mmboltfrom
bottomrightofpanelbelow
steeringcolumn.Unsnappaneland
pullawaytogainaccessbehind
panel.(FigureB)
6. Remove(1)10mmboltonbottom
leftofcenterpanelbehindpanel
belowsteeringcolumn.(FigureB)
 Continued on next page
(Figure B)
Toyota 4 Runner 2003-2009 (excluding Limited)
(Figure A)
(Figure B)
A/C
0
1
2
3
4
5
(Figure A)
PASSENGER
SECURITY
A/C
0
1
2
3
4
5
