Metra Electronics 95-8202 - Kit Assembly Instructions; Kit Preparation Steps; Double DIN Radio Provision Assembly

16
Kit Preparation
1. Locatethefactorywiringharness
inthedash.Metrarecommends
usingthepropermatingadapter
fromMetraorAXXESS.Re-connect
thenegativebatteryterminaland
testtheunitforproperoperation.
2. Attachthefactorymounting
bracketsandthe95-8202double
DINtrimplatestothedoubleDIN
radiowiththescrewssupplied
withtheunit.(FigureB)
NOTE: Remove locating
pins from factory brackets
with grinder.
4. Reassembledashinreverseorder
ofdisassembly.
Double DIN radio provision
(Figure A)
NOTE: For all Scion TC and XA you
will need to cut off the front upper
section of the Double DIN trim
plates, as shown by dotted lines
labeled “A” in (Figure A).
For the 2001-2005 Toyota Rav4,
2001-2007 Toyota Highlander,
2003-2006 Toyota Tundra and
2003-2007 Toyota Sequoia you will
need to cut off the rear section
of the double DIN trim plates, as
shown by dotted lines labeled “B” in
(Figure A).
For all other vehicles
skip to Step 1.
(Figure A)
A
A
B
B
Kit Assembly 95-8202
Factory
brackets may differ
