Dash Disassembly 95-8202
1. Unclipandremovesidepanelfrom
bothsidesofradioandclimate
controls.(FigureA)
2. Remove(4)Phillipsscrews
securingtheradio/climatecontrol
trimpanel.(FigureB)
3. Remove(4)10mmboltssecuring
theradio.(FigureC)
4. Unplugandremoveradio.
5. Removefactorybracketsfrom
radio.Retainbracketsforuse
duringkitassembly.
 Continue to kit assembly
Toyota Rav4 2001-2005
(Figure C)
1. Unsnapthelowertrimpiecefrom
eachsideofthedashconsoleand
remove(2)Phillipsscrewsexposed
ineachcavity.Removetheupper
trimpiecefromeachsideofthe
console.(FigureA)
2. Removetheclimatecontrolknobs
and(2)Phillipsscrewsexposed.
Removetheclimatecontroltrim
bezel.(FigureA)
3. Removetheashtrayand(1)10mm
boltexposed.Uncliptheashtray
trimbezelandremove.(FigureA)
4. Uncliptheradiotrimbezel,remove
(4)Phillipsscrewssecuringthe
unitanddisconnectthewiring.
5. Removefactorybracketsfrom
radio.Retainbracketsforuse
duringkitassembly.
 Continue to kit assembly
Toyota MR2 Spyder 2000-2003
(Figure A)
(Figure B)
(Figure A)
