Dash Disassembly 95-8202
1. Pullandremovedashpanelfrom
radioandclimatecontrols.Tip:
Thereare8clips.(FigureA)
2. Remove(6)10mmboltsfromradio
andclimatecontrolsassembly.
(FigureB)
3. Removeassemblyanddisconnect
thewiring.
4. Remove(8)Phillipsboltsand
(4)Phillipsscrewstoseparate
bracketsfromassembly.Retain
bracketsforuseduringkit
assembly.(FigureC)
 Continue to kit assembly
Toyota Highlander 2001-2007
(Figure C)
1. Unclipthebottomedgeoftheradio
trimpanelthenliftupandoutto
remove.(FigureA)
2. Remove(4)10mmboltssecuring
thefactoryradio.(FigureB)
 Continue to kit assembly
Toyota Matrix 2005-2008
(Figure B)
(Figure A)
(Figure A)
(Figure B)
