Metra Electronics 95-8202 - Scion XB 2008-up Dash Disassembly; Scion TC 2005-2010 Dash Disassembly

13
Dash Disassembly 95-8202
Scion XB 2008-up Scion TC 2005-2010
1. Unclipandremovethetrimpanel
aroundtheradioincludingtheA/C
vents.(FigureA)
2. Unclipandremovethetrimpanel
atthebottomedgeofthedash
cavity.(FigureB)
3. Remove(4)10mmboltssecuring
theradio.(FigureC)
 Continue to kit assembly
(Figure C)
(Figure B)
(Figure A)
1. Unsnaptrimfromaroundshifter
(notnecessarytoberemoved).
(FigureA)
2. Unclipandremovepanelfrom
aroundradio(includingclimate
controlsandradiodoor).(FigureB)
3. Remove(2)10mmnutsfrom
thetopmountinglocationsand
(2)10mmboltsfromthebottom
mountinglocationstoremovethe
radio.(FigureC)
4. Removefactorybracketsfrom
radio.Retainbracketsforuse
duringkitassembly.
 Continue to kit assembly
(Figure C)
(Figure B)
(Figure A)
