Dash Disassembly 95-8202
Scion TC 2011-up
1. Unclipradiotrimpanel.Unplugandremovepanel.(FigureA)
2. Remove(4)Phillipsscrewssecuringtheradio.Unplugandremoveradio.
(FigureB)
3. Removefactorybracketsfromradio.Retainbracketsforuseduringkit
assembly.(FigureC)
 Continue to kit assembly
Scion XD 2008-up
1. Unclipandremovetheradiotrim
panel.(FigureA)
2. Remove(4)10mmboltssecuring
theradio.(FigureB)
3. Removefactorybracketsfrom
radio.Retainbracketsforuse
duringkitassembly.
 Continue to kit assembly
(Figure B)
(Figure A)
(Figure A) (Figure B)
(Figure C)
