Metra Electronics 95-8202 - Subaru BRZ 2013 Dash Disassembly; Subaru Forester 2009-2013 (with SD based navigation) Dash Disassembly

15
Dash Disassembly 95-8202
Subaru BRZ 2013
1. Unclipandremovethetrimpanel
surroundingthefactoryradio
includingtheA/Cvents.(FigureA)
2. Remove(4)Phillipsscrews
securingtheradio.Unplugand
removetheradio.(FigureB)
 Continue to kit assembly
Subaru Forester (with SD based navigation)
2009-2013
1. Unclipandremovethepanelfrom
aroundtheradio.(FigureA)
2. Removefour10mmboltsand
removefactoryradio.(FigureB)
Continue to kit assembly
(Figure A)
(Figure B)
(Figure B)
(Figure A)
