Metra Electronics 95-8202 - Toyota FJ Cruiser 2007-up Dash Disassembly

9
Dash Disassembly 95-8202
1. RemovetwoPhillipsscrewsfrom
bottompartofsidetrimpanels.
(FigureA)
2. Usingapanelremovaltool,
carefullyremovethesidetrim
panels.(FigureB)
3. Remove(2)Phillipsscrewsfrom
radiotrimpanel.(FigureC)
4. Usingpanelremovaltool,carefully
removeradiotrimpanel.
(FigureD)
5. Remove(4)10mmboltssecuring
theradio.
6. Unplugandremoveradio.
7. Removefactorybracketsfrom
radio.Retainbracketsforuse
duringkitassembly.
 Continue to kit assembly
(Figure C)
Toyota FJ Cruiser 2007-up
(Figure A)
(Figure D)
(Figure B)
