Metra Electronics 95-8202 - Toyota Celica 2000-2005 Dash Disassembly; Toyota Echo 2000-2005 Dash Disassembly

4
Dash Disassembly 95-8202
1. Unclipandremovethegearshifter
trimbezelandremove(2)Phillips
screwsexposedbelowtheclimate
controls.(FigureA)
2. Pulloffclimatecontrolknobsand
remove(2)Phillipsscrewsexposed.
(FigureA)
3. Uncliptheclimatecontrol/factoryradio
trimbezelandremove.(FigureA)
4. Remove(4)10mmscrewssecuring
thefactoryradioanddisconnect
thewiring.
5. Removefactorybrackets
fromradio.Retainbracketsforuse
duringkitassembly.
 Continue to kit assembly
Toyota Celica 2000-2005 Toyota Echo 2000-2005
(Figure A)
1. Removetheclimatecontrolknobs
and(2)Phillipsscrewsexposed.
Unclipandremovetheclimate
controltrimbezel.Depresstheside
clipssecuringtheclimatecontrol
panelandmovethepaneltoaccess
(2)Phillipsscrewsfromthetopof
thefactoryradiobrackets.
(FigureA)
2. Removetheashtray.Unclipand
removetheradiotrimbezel.Remove
(2)Phillipsscrewsfromthebottom
oftheradiobracketsanddisconnect
thewiring.
3. Removefactorybracketsfromradio.
Retainbracketsforuseduringkit
assembly.
 Continue to kit assembly
(Figure A)
