MI 3201 TeraOhm 5 kV Plus Working with your Results
41
Step voltage
Function name
Last measured insulation resistance
Set test voltage
Actual test voltage - measured value
Actual test current - measured value
Capacitance of the tested object
Complete duration of the measurement
First step measured resistance with its nominal voltage
First step actual test voltage - measured value
Second step measured resistance with its nominal voltage
Second step actual test voltage - measured value
Third step measured resistance with its nominal voltage
Third step actual test voltage - measured value
Fourth step measured resistance with its nominal voltage
Fourth step actual test voltage - measured value
Last step measured resistance with its nominal voltage
Last step actual test voltage - measured value
Ser. number of the stored result
Date *
Time *
Note:
*Date and time of storing the test result are transferred to PC while date and time
of recalling are displayed when recalling results.
6.2 Transferring Data to a PC
Stored results can be transferred to a PC. A special communication program TeraLink-
PRO has the ability to identify the instrument and download the data.
How to transfer the stored data:
Connect the instrument to the COM port of the PC using the communication cable
(RS232 or USB).
- Power up both the PC and the instrument.
- In the CONFIGURATION menu of the instrument (chapter 4.2), set the
communication mode (RS232 or USB) and Baud Rate appropriately. At the end,
leave the CONFIGURATION menu by pressing the ESC button.
- Run the Teralink-PRO program on the PC. In the Configuration / Com Port menu,
set the Com Port and Baud Rate appropriately. The Auto Find function can be used
to configure Com port Settings automatically. If Auto Find function is not successful
first time, try one more time.
- The PC and the instrument should automatically recognize each other.
With the TeraLink program, the following tasks can be performed:
-- download data;
-- clear instrument data;
-- change and download user data;
-- prepare a simple report form;
-- prepare a file to import in to a spreadsheet program.
The program Teralink-PRO is a Windows 2000/XP/VISTA
TM
based PC software
