2.12 TIP, Titration procedure
794 Basic Titrino
63
Information for the commands (steps):
Command Meaning Input range
method Method from the user memory. This method runs as a
submethod.
Name
pause Waiting time. The waiting time can be aborted with
<QUIT>.
<CLEAR> sets "inf" (= infinitely long pause time).
0...999999 s,
inf.
L4, L6 output Set L4 output (pin 3) resp. L6 output (pin 1) of the
remote socket.
active = 0 V, inactive = 5 V, pulse > 100 ms, off =
output is not used.
Cable Titrino (L6) - Dosimat: 6.2139.000.
Important: A pulse (e.g. a pulse from monitoring or an
activate pulse in a submethod) can set an active output
to inactive! At the end of the TIP method, the outputs are
set to "inactive".
active,
inactive,
pulse, off
info Message in the display .
The TIP sequence is held and the message displayed.
Continue the sequence with <START>, <QUIT> or
<ENTER>.
up to 16
characters
The parameters of the sequence can be viewed and changed at any time under the
<PARAM> key.
