2.1 Operating principles
Metrohm 838 Advanced Sample Processor, Operation 13
2.1.5 Data input
Input line
Either one or two parameters can be entered in a menu line or a se-
quence. A blinking block cursor indicates where a parameter can be
entered.
>stirring rates
stirrer tower 1 █ 3
 Title line
 Input line
  
Menu entry Cursor Parameter
>sample sequence
04 STIR █ T1 : 1 s
 Title line
 Input line
  
Command 1
st
parameter 2
nd
parameter
Switching between the parameters is carried out with the arrow keys
<> and <>. <ENTER> moves the cursor automatically to the
right, <QUIT> moves it to the left.
<Select> list
SELECT
Data can usually be entered directly by the numerical keys of the keypad.
For entries marked by a colon the <SELECT> key can be used to dis-
play a selection of entries. This selection is cyclically arranged like a re-
volving drum.
Example:
9600
4800
2400
1200
600
<SELECT>
>RS232 settings
baud rate: 9600
>RS232 settings
<ENTER>
baud rate: 2400
Fig. 3 Selection list
