Metrohm 838 Advanced Sample Processor User Manual

2.2 Configuration
20 Metrohm 838 Advanced Sample Processor, Operation
2.2.3 Rackdefinitionen
configuration
>rack definitions
Submenu for defining individual racks
Open the submenu with <ENTER>
>rack definitions
>>recall rack
Load rack definitions
In order to make a modification to the definition of a sample rack the rack
data must first be loaded. The data of the Metrohm standard racks is stored
under their ordering number.
>recall rack
name: 6.2041.450
Name of the rack to be loaded
10 ASCII characters
The <SELECT> key can be used to make a selection from the saved rack
data. The rack data is loaded with <ENTER>. The first selection to appear
is the rack name of the currently attached rack.
>recall rack
code 000001
Magnet code of the rack
See table on p. 65.
000001…111111
The magnet code is used for the unambiguous identification of the rack. The
magnet code is recognized during the initialization of the rack. This is why
the <RACK> key should be pressed whenever a rack is changed.
For security reasons the max. stroke path should be set before modifications
of the lift positions are made, see section 2.2.1.
>recall rack
work position T1 0 mm
Working position for sample positions *
)
0…235 mm (in mm from upper stop point)
>recall rack
rinse position T1 0 mm
Rinsing position for sample positions *
)
0…235 mm (in mm from upper stop point)
>recall rack
shift position T1 0 mm
Shifting position for sample positions *
)
0…235 mm (in mm from upper stop point)
>recall rack
special pos. T1 0 mm
Special position for sample positions *
)
0…235 mm (in mm from upper stop point)
>recall rack
beaker radius * mm
Effective beaker radius for the sample
positions on the rack
*, 1…100 mm * = any value
This setting is required for the check of the beaker radius, see p. 17.
Use <QUIT>
for next hig
h
e
r
l
eve
l
