3.2 Mounting accessories
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
18
￭￭￭￭￭￭￭￭
892 Professional Rancimat
2
Mounting the tubing for the air supply
￭ Screw the FEP tubing 250 mm to the air supply connections of the
892 Professional Rancimat.
3
Inserting the reaction vessel
￭ Fill the reaction vessel with the sample.
￭ After the required reaction temperature has been reached, insert
the reaction vessel with the mounted reaction vessel cover in the
openings provided on the 892 Professional Rancimat.
4
Establishing the tubing connections
￭ Connect the white silicone tubing that is connected to the mea-
suring vessel cover to the tubing connector of the reaction vessel
cover.
￭ Screw the FEP tubing 250 mm which is connected to the M8/olive
tubing adapter of the 892 Professional Rancimat to the M8/M6
thread adapter of the reaction vessel cover.
NOTICE
The optional clear glass measuring vessels (6.1428.030) may also be
used in place of the polystyrene measuring vessel (6.1428.107).
In contrast to the polystyrene vessel, the measuring vessel (6.1428.030)
can also be cleaned with acetone.
3.2.5 Mounting the exhaust air collection tube
The optional exhaust air collection tube (6.2757.000) can be mounted on
the 892 Professional Rancimat for targeted removal of the exhaust air.
NOTICE
A total of 8 pieces of silicone tubing (6.1816.010) (220 mm) are
required in addition to the exhaust air collection tube.
