8.7 Component Parts
PART NO. DESCRIPTION QTY.
30-4413615 136PC15G2 PRESSURE SENSOR 1 U103
99-3104003 1N4003 DIODE 3 D302-304
98+3827002 2N7002 N KANAL MOSFET SOT23 1 Q200
30-4491004 4MHZ CST4.00MGW RESONATOR
0,5%
1 X150
30+4407402 74HC02 SMD SO14 1 U203
30+4107414 74HC14 SO14 SMD IC 1 U250
30+4407432 74HC32T SMD SO14 1 U202
30+4174595 74HC595 SO16 SMD IC 1 U251
30+4474040 74HCU04 SO14 SMD IC 1 U151
30-4407806 7805 TO220 5V REGULATOR 1 U303
30-4407812 POS. 12V REG. TO220 1 U301
30-4407815 7815 TO220 +15V REGULATOR 1 U300
30+4261203 AD-CONVERTER SO16-300 1 U150
30+2803150 BLM31A601SPTM00-03 K 1206 1 L150
30-5602601 PKB24SPC-3601 PIEZO BUZZER 1 B250
30-3210270 BYV27-100 2A 100V DIODE 4 D201-204
30-2410812 1000uF 35V LXF EL.L 12,5MM 1 C300
30-2410714 100uF 35V SME-VB EL.L 8MM 8 C201, C302, C304-305, C308, C310-312
98+2502615 10uF 16V KANNE D LAV ESR 6 C150-151, C156, C200, C301, C307
98+2713210 1nF X7R 10% 0805 3 C106, C204-205
98+2713122 220pF COG 10% 0805 1 C253
C22nF-1206 22nF NPO 10% 1206 1 C111
C33pF-0805 33pF 10% 0805 2 C158-159
98+2713348 47nF X7R 10% 0805 24 C100, C102-103, C105, C108, C110,
C152-155, C157, C160-161, C202-203,
C209-210, C250-252, C303, C306,
C309, C313
98+2713247 4.7nF X7R 10% 0805 1 C206
30-5516204 6442-04 4P KONNEKTOR 1 P300
30-5516206 6442-06 MOLEX 1 P301
30-5516102 6471-02 2P KK KONTAKT 4 P251-254
30-5516106 6471-02 6P KK KONTAKT 1 P200
30-5650016 09185166803 16P FL.K.KONT 1 P250
30-2803110 DSS306-91FZ103N100 EMI FILTER 7 L250-254, L300-301
