Metronix ARS 2100 SE Series Mounting Instruction

Additional requirements for the servo drives concerning the UL approval Page 16
Range ARS 2102 SE ARS 2105 SE ARS 2108 SE
Metronix part number – with STO 9200-2102-30 9200-2105-30 9200-2108-30
Metronix part number – without STO 9200-2102-31 9200-2105-31 9200-2108-31
Auxiliary equipment Counterplug PHOENIX Mini-Combicon MC1.5/8-STF-3.81 BK
(only for devices with STO)
Power connector set 9200-0210-20 9200-0218-20
Signal connector set 9200-0200-00
Shield connector set 9200-0202-00
Internal brake resistor [X9]:
Brake resistance
60 37 
Pulse power
2,4 kW 3,9 kW
Continuous power
10 W 20 W 25 W
Threshold
limit
389 V
Max. voltage 400 V
External brake resistor [X9]:
Brake resistance external  50   25 
Continuous power  2500 W
Max. operating voltage (at output) 460 V 400 V
Motor connection specifications [X6]:
Specifications for operation with 1x 230 VAC [± 10%], 50 Hz
Output power 0,5 kVA
1,0 kVA 1,5 kVA
Max. output power for 5 s 1,0 kVA
2,0 kVA 3,0 kVA
Output current 2,5 A
RMS 5 A
RMS
8 A
RMS
Max. output current for 5 s 5 A
RMS 10 A
RMS
16 A
RMS
Max. output current for 0,5 s 10 A
RMS 20 A
RMS
32 A
RMS
(fel ≥ 3 Hz) *)
*) with smaller electrical
rotational frequencies (f
el
)
shorter permissible times are
valid for ARS 2108 SE
Max. mains current for continuous
operation
2,4 A
RMS
4,7 A
RMS
10 A
RMS
Max. PWM frequency 20 kHz (software programmable)
As a guideline: Power
loss/efficiency (with regard to the
rated output power)
typical 8% / 92%
Mounting Instructions „Servo drives ARS 2100 SE“ Version 5.0
