Additional requirements for the servo drives concerning the UL approval Page 39
5.11 SD-/SDHC-/MMC-Card slot
The ARS 2100 SE servo drive comprises a SD-/SDHC-/MMC-Card slot for the support of Firmware
downloads (initialisation via boot switches) and uploads and downloads of parameter sets.
SD-Card slot
Card types SD, SDHC and MMC
File systems FAT12, FAT16 and FAT32
Functions Load a parameter set (DCO file), save the current parameter set (DCO file),
load a firmware file
File names
Only file and directory names according to the 8.3 standard are supported.
5.11.1 BOOT-DIP-Switch
During a restart/reset, the BOOT-DIP-Switch is used to determine whether to perform a firmware
download from the SD-/MMC-Card or not. The position of the switch is shown in Figure 1.
BOOT-DIP-Switch in position “ON” firmware download requested
BOOT-DIP-Switch in position “OFF” firmware download not requested
When there is no SD-/MMC-Card in the card slot of the servo drive and the BOOT-DIP-Switch is in the
position “ON” (firmware download requested), the error 29-0 is triggered after a restart/reset.
This error stops all further performances. This means that there is no communication possible via USB.
Mounting Instructions „Servo drives ARS 2100 SE“ Version 5.0
