MFJ-223 Vector Impedance Antenna Analyzer
MFJ Enterprises, Inc 3 Version 1
Power Management
o Power Source: Built-in 3.7-V, 1800-mAh Lithium
Polymer battery
o Charge Controller: Smart charger, LED charging-status
indicator
o Voltage Monitor: On-screen DVM, plus battery
condition icon
o Charger Source: Any USB port, analyzer accepts
Micro-USB plug
o Power Savers: Auto-off timer, manual Run/Stop RF-
generator control
Interface
o RF Connector: BNC, PL-259 with adapter
o Battery Charge Connector: Micro-USB
o Screen: 2-inch high-output color TFT
o Function Keys (4): Membrane, with on-screen (soft-
menu) identifiers
o Tuning: Rotary encoder with press-in tuning-step
selection
o ID Tag: Programmable call letters or name, up to 8
characters.
Weight and Dimensions
o Case: High-impact black molded
o Size: 2.7" wide x 3.5" high x 1.0" deep (6.86 cm x 8.9
cm x 2.54 cm)
o Weight: 5.1 oz (.144 kg)
