MFJ 226 - Page 3

Impedance Magnitude Screen (Z):...........................................12
Resistance Screen (R): ............................................................12
Reactance Screen (+X or -X):..................................................13
Return Loss (S11): ...................................................................13
Phase Angle (Deg): ..................................................................13
Smith Chart Screen: .................................................................14
CALIBRATION ..................................................................................14
Global Calibration File ..................................................................15
Building a Local Calibration File ...................................................15
Executing Global Calibration ........................................................16
CALIBRATION LOAD SET ...............................................................17
USING YOUR PC TO COMMAND THE ANALYZER.......................18
Computer Software Control ..........................................................18
Manual Control via Computer.......................................................19
FIRMWARE UPDATE PROCEDURE...............................................19
12 MONTH LIMITED WARRANTY...................................................21
Important Note: Before turning on your analyzer for the
first time, we strongly recommend reading through the
entire manual. You will find valuable operating information
along with important tips to help you take full advantage
its full range of features.
The MFJ-226 is accurately calibrated at the factory and
should not need recalibration for initial use.
Do not run CALIBRATE with out proper calibration loads.
The display window has a plastic film applied at the
factory to protect the display window from scratches in the
manufacturing process. This film can be removed if
desired.
Note: To increase battery life it is recommended that you
set the BACKLIGHT to AUTO and AUTO POWER OFF to
ENABLE in the SETTINGS Menu (see page 6).
Firmware version V01R02
