TECHNICAL SPECIFICATIONS OF THE PRODUCT
WT1SC gearmotor, for swing gates
• Product type: electromechanical gearmotor for the automation of automatic gates and doors with built-in control unit complete with radio recei-
ver for “GTX4” transmitters
• Adopted technology: DC motor; epicyclical gear reducer; manual motor release. An internal power supply unit housed inside the motor but sep-
arated from the control unit, reduces the mains voltage to the nominal 24Vdc voltage used in the whole automation system
• Maximum torque: 100 Nm
• Nominal torque: 50 Nm
• No-load speed: 0,20 rad/s ÷ 0,30 rad/s
• Speed at nominal torque: 0,16 rad/s ÷ 0,24 rad/s
• Maximum frequency of operating cycles: 100 cycles per day (1 cycle = opening + closing). The control unit limits cycles to a maximum of
approx. 50 cycles per hour
• Maximum time for continuous repetition of cycles: about 10 minutes
• Application limits: the product can be used with gates with weights up to 180 kg (leaf of 0.8 m) or with leaf lengths of up to 1.6 m and opening
angle up to 110°
• Mains power-supply: 230 Vac (+10% -15%) 50/60 Hz
• Absorbed power: 120 W
• Backup power supply: for “PR2” buffer batteries
• Flashing light output: for flashing lights with 12 V (maximum 21 W) bulb
• “ECSBus” output: 1 output with maximum load of 7 ECSBus units
• “OPEN” input: For normally open contacts (closure of the contact prompts the “OPEN” command)
• “STOP” input: for normally open and/or 8.2kohm constant resistance type contacts, or normally closed contacts with self-learning of the "nor-
mal" status (a variation with respect to the memorised status generates a “STOP” command
• Radio Aerial input: 50 ohm for RG58 or similar type cable
• Max. cable length: mains power-supply: 30 m; motor outputs: 10 m; other inputs/outputs: 20 m with aerial cable preferably less than 5 m
(observe warnings regarding the minimum section and type of cables)
• Ambient operating temperature: -20 ÷ +50 °C (gearmotor efficiency is reduced at lower temperatures)
• Use in particularly acid, saline or potentially explosive atmospheres: no
• Assembly: vertical, with dedicated fixing plate
• Protection rating: IP 44
• Dimension / weight: 385 x 90 x 123 mm / 4,8 Kg
• Possibility of radio control: with “GTX4” transmitters, the control unit is set to receive one or more of the following commands: “OPEN”, “Partial
Open”, “Only Open” and “Only Close”
• Compatible GTX4 transmitters: up to 256 if memorised in “Mode I”
• GTX4 transmitter range: from 50 to 100 m. This distance may vary in the presence of obstacles and/or electromagnetic disturbance present,
and is influenced by the position of the receiving antenna built into the FL100 flashing light
• Programmable functions: “semi-automatic” function (after opening the control unit does not re-close the gate automatically) or “automatic” fun-
ction (after opening the control unit re-closes the gate automatically); motor speed “low” or “high”; in the case of “automatic” mode the pause
time can be selected from 10, 20, 40, and 80 seconds; “pedestrian” opening can be selected in 4 different modes; system obstacle detection
sensitivity can be selected from 4 levels; “Open” command operation can be selected from 4 modes
• Self-programmed functions: self-detection of devices connected to output “ECSBus”; self-detection of type of “STOP” device (contact type NO,
NC or 8.2 kohm constant resistance); self-detection of the opening angle for each motor; self-detection of number of gearmotors present in auto-
mation (1 or 2)
WT1SK gearmotor, for swing gates
• Tipologia: electromechanical gearmotor for automations of automatic gates and doors
• Product type: DC motor; epicyclical gear reducer; manual motor release
• Maximum torque: 100 Nm
• Nominal torque: 50 Nm
• No-load speed: 0,20 rad/s ÷ 0,30 rad/s
• Speed at nominal torque: 0,16 rad/s ÷ 0,24 rad/s
• Maximum frequency of operating cycles: 100 cycles per day (1 cycle = opening + closing). The WT1SC gearmotor control unit limits cycles to
a maximum of approx. 50 cycles per hour
• Maximum time for continuous repetition of cycles: about 10 minutes
• Application limits: the product can be used with gates with weights up to 180 kg (leaf of 0.8 m) or with leaf lengths of up to 1.6 m and opening
angle up to 110°
• Power supply: 24 Vdc (50%)
• Rated current absorption: 2A; on start-up the maximum absorbed current is 3A for a maximum time interval of 2 s
• Ambient operating temperature: -20 ÷ +50 °C (gearmotor efficiency is reduced at lower temperatures)
• Use in particularly acid, saline or potentially explosive atmospheres: no
• Assembly: vertical, with dedicated fixing plate
• Protection rating: IP 44
• Dimensions / weight: 385 x 90 x 123 mm / 4,3 Kg
English
English – 33
