Programming the Radio Parameters
83
Note
The available frequency ranges are:
• Reception: 100 kHz to 30 MHz.
• Transmission: 1.6 to 30 MHz.
• BAND
Select the channel SSB mode:
• USB – upper sideband mode
• LSB – lower sideband mode.
• MODE
Select the channel radio operating mode:
• SSB – single sideband
• AME – amplitude modulation equivalent
• PLT – single sideband with pilot signal.
• AGC
Select the channel Automatic Gain Control mode. MICOM-3 offers two AGC
response speeds: SLOW and FAST. You can also turn the AGC OFF completely.
• BW
Select the default channel filter bandwidth:
• 2.1 K
• 2.7 K
• 3.0 K
• 3.3 K
• LSM (Low Speed Modem)
• CW (Continuous Wave). The bandwidth used in this case is selected by
MENU>PROG>RAD>PRMT>CW.
Note
The factory-default parameter values are as follows:
• Rx Frequency 15.000.00 MHz
• Tx Frequency 15.000.00 MHz
• SSB Mode (Band) USB
• Bandwidth 2.7K
• Tx Power MAX
• AGC Type SSB
