Page 23
Commissioning
IF2030/ENETIP
Class Instance Attribute Data type Name RS485 RS422 Description
0x0320 1
Sensor block Request sensor information
0 Uint8 R Number of objects
1 Uint8 RW block index offset
The offset lets you scroll through existing
sensor blocks [0 - 0x1F]
2 Uint8 RW page index to read
Specifying an index lets you scroll through
existing pages
3 Uint8 R number of pages Max. number of pages
4 Uint8 R measurement unit Signal unit
5 Int32 R article number Part number
6 Int32 R Option Option
7 Int32 R Batch number Batch number
8 Int32 R serial number Serial number
9 Float R
Nominal measuring
range
Nominal measuring range
10 Float R Nominal offset Nominal offset
11 Float R current measuring range Actual measuring range
12 Float R current offset Actual offset
13 Uint8[32] R Target material Target material
14 Uint8[32] R Sensor/channel name Sensor/channel name
15 uint8 R extension length Length of block extension
16 uint8[138] R extension
