Page 24
Commissioning
IF2030/ENETIP
Class Instance Attribute Data type Name RS485 RS422 Description
0x0390 1
Parameter Info
Request configuration parameters, e.g., sensor
exposure time, request via subindex 1, configure
interface with Class 0x2510 through 0x2540
0 Uint8 R Number of objects
1 Uint16 RW Parameter ID
Please refer to the sensor documentation for
available parameter IDs and their types
2 Uint8[14] R Name
3 Uint8[8] R Unit
4 Uint8[8] R Type
0x0410 1
Float parameter Read or write float parameter
0 Uint8 Number of objects
1 Uint16 RW Parameter ID
Please refer to the sensor documentation for
available parameter IDs and their types
2 Uint8 RW Reserved
3 Float RW Value Value
4 Uint8[14] R Name Designation
5 Uint8[8] R Unit Unit as a string
6 Float R Min
7 Float R Max
