MICRO-EPSILON IF2030/ENETIP User Manual

Page 27
Commissioning
IF2030/ENETIP
If time synchronization has been enabled on the scanner (SPS), a synchronized signal can be tapped at the S+/S- terminal. Signal
timing can be configured by using Class 0x43, Instance 1, Attribute 300.
Parameter Unit Default Min Max Comments
Byte 0 - 3 Sync Intervall ns 500,000,000 10,000 500,000,000 Synchronization interval 10 µs ... 500 ms
Byte 4 - 7 Sync Offset ns 0 0 Sync Interval -1
Byte 8 - 11 Res. Sync Interval ns 500,000,000 10,000 500,000,000
Byte 11 - 15 Res. Sync Offset ns 150 0 Res. Sync Interval - 1 |Sync Offset – Res. Sync Offset| > 150
Byte 16 - 19 Pulse Length µs 4 1 500
Pulse length < min
(SyncOffset, Res.Sync Offset)
Changes only take effect after IF2030/ENETIP has been restarted.
Please use Class 0xA0, Instance 1, Attribute 7 to configure the level (TTL/HTL).
