8
FM 750 GFN Flowmeter
P/N 11501
14” Nylon cable ties (10)
P/N 12910
10’ 3-Pin M/P Extension Cable
P/N 13206
Component Parts and Assembly Hardware (cont)
5’ Hall-effect Flow Sensor
Cable with Threaded Sensor
P/N 13096
A B C
F G H J K
A B C D E
C B A
10’ FLOW, SERVO, BOOM
UNIVERSAL HARNESS KIT
P/N 01026
NO TIE
(SERVO)
GREEN TIE
(FLOW)
NO TIE
(BOOMS 1-4)
RUN/HOLD
RELAY CONNECTION
C B A
A B C D E
C B A
10’ RUN/HOLD, SPEED,
POWER HARNESS
P/N 13090
YELLOW TIE
(SPEED)
POWER
GREY TIE
(RUN/HOLD)
RELIEF VALVE
RELAY CONNECTION
