micro-trak MT-2400 LR - Component Parts

Speed Sensor Kit P/N 01531 (1)
Including items A-G, below:
Owner’s Manual
P/N 13243
MT-2400 Console
Model MT24-97-LR
(P/N 13242)
A. 5’ Hall-effect Speed/Flow Sensor Cable
P/N 13096
G. 15’ 3-Pin Extension Cable M/P 150
P/N 13207
7
F. 14” Nylon cable ties (10)
P/N 12910
C. Magnet Clip (6)
P/N 10080
E. Hardware Bag
P/N 13251
B. Speed Sensor
Mounting Bracket
P/N 10013
M-T 1” Electric
Servo Valve
P/N 11218
5’ 3-Pin W/P Extension
Cable P/N 10450
10’ 3-Pin W/P Extension
Cable P/N 10449
D. Magnets (6) P/N 12069
(2 in hardware bag)
Component Parts and Assembly Hardware
Before beginning installation, check the carton contents for the following items:
(2)
(2)
(2)
(2)
(2)
(2)
(2)
REFERENCE MANUAL
AUTOMATIC RATE CONTROLLER
MT-2400
TM
LR
Console Mount Kit
P/N 13181
