MT-2400 System Layout
9
FLOWMETER
GREY TIE
YELLOW TIE
15' 3-PIN
M/P EXTENSION
GREEN TIE
TEE “B”
TEE “C ”
5' 3-PIN
W/P EXTENSION
OPTIONAL
RUN/HOLD RELAY
CONNECTION (BROWN WIRE)
RUN/HOLD
RELAY
+
T
O 12-VOLT
SOURCE
TO RUN/HOLD RELAY
CONNECTION (BROWN WIRE)
ON THE MAIN HARNESS.
OPTIONAL
RELIEF VALVE RELAY
CONNECTION (RED WIRE)
SWITCH
BOX*
MT-2400
CONSOLE
10' 3-PIN
W/P EXTENSION
THROTTLE VALVE*
* ITEMS NOT INCLUDED WITH SYSTEM.
+
OPTIONS AVAILABLE FROM MICRO-TRAK.
TEE “A”
AGITATION
VALVE*
STRAINER*
PUMP*
SERVO
VALVE
TANK
SHUT-OFF VALVE*
SPEED
SENSOR
(GREEN BODY)
RUN/HOLD
SENSOR*
(BLACK BODY)
IGNITION*
10' 3-PIN
M/P EXTENSION
