P/N 14812
1. Ground
2. Signal
3. +12 Volts
4. N/C
2 1
4 3
4 2
3
1
P/N 14814
1. 12 Volts
2. +12 Volts
3. Signal
4. Ground
2 3
1 4
3 2
4 1
P/N 14816
1. Ground
2. Signal
3. +12 Volts
4. Enable
4 3
1 2
1
2
4
3
P/N 14817
1. Ground
2. 12 Volts
3. Signal
1
3
2
P/N 14818
A. 12 Volts
B. 12 Volts
C. Signal
D. Ground
C D
B A
D
C
A B
P/N 14815
A. Ground
B. Signal
C. 12 Volts
D. 12 Volts
C D
B
A
D C
A B
P/N 14811
P/N 14813
1. +12 Volts
2. Ground
3. Signal
4. Enable
3 4
2
1
4
3
1
2
P/N 14810
Signal
Ground
Common
B A
DICKEY-john Radar Ford Connector
DICKEY-john Radar Deutsch Connector
DICKEY-john Radar Cannon Connector
DICKEY-john Radar Amp Connector
In-Cab John Deere Metri-Pack Connector
8000/9000 Series
Raven Radar Conxall Connector
Magnavox & Phillips Radar Packard Connector
DICKEY-john Radar Packard Connector
In-Cab John Deere “Y” Connector
P/N 14926
Vansco Radar Amp Connector
RADAR CONNECTOR SIGNAL PIN
DICKEY-john
Amp 2
DICKEY-john
Cannon 3
DICKEY-john
Deutsch 3
DICKEY-john
Ford 2
DICKEY-john
Packard B
In-Cab JD (8000 & 9000’s
Metri-Pack A
Magnavox & Phillips
Packard C
Raven
Conxall 3
Vansco Amp 2
1
2
3
