micro-trak MT-3405 M - Basic Overview of Typical Installation

7
Basic Overview of Typ i cal MT-3405 M Installation
Pull-Type Sprayer
Hall-eect Speed Sensor
Magnets on Hub of
Non-driven Wheel
MT-3405 M Console
Remote Run/Hold
Harness Connection
Battery
Agitation Shot-o Valve *
Stainer *
Pump *
Servo
Main Harness Hitch Connectors
Trottle Valve *
Flowmeter installed after
the agitation/return line,
pressure regulator and lter,
but before the boom valve
* Items NOT Included with the MT-3405 FTW
Boom Shut-o Valves *
