micro-trak MT-3405 M - MT-3405 M Plumbing Overview Diagram

Tee “B”*
Throttle valve*
* Items not included with system.
Tee “A ”*
Agitation
valve*
Strainer*
Pump*
Tank
shut-o valve*
Speed sensor
(green body)
Yellow tie
Optional
relief
valve
Servo
valve
To booms
Flow sensor
(green body)
Brown
tie
Red
tie
Orange
tie
Yellow
tie
Green
tie
Natural
tie
Optional
pressure
sensor
1
2
3
4
5
Run/hold sensor*
(black body)
Battery*
Local access
run/hold connection
Remove jumper cover
to congure for ball valves
Local access
speed connection
A B C
A B C
A B C
3405 M Console
A B C
A B C
Gray tie
Green
tie
SC-3405
Module
A B
A B
A B
A B
A B
A B
A B
A B
A B
A B
A B
A B
A B
A B
A B
A B
A B C
20
Installation (cont)
MT-3405M Plumbing Overview Diagram
