5.2 Checks Prior To Start-Up
• Ensure the MPPT is mounted vertically.
• Check input output cables are secured.
• Check the polarity of the panel and battery and they are correct.
• Check if the Panel Voltage meets the MPPT rating required.
5.3 MPPT Start-up Procedure
• Always turn on battery breaker first.
• Wait until MPPT Display states that the MPPT is sleeping.
• Turn on Panel Breaker.
• MPPT will track the PV Panels.
• MPPT will start charging the batteries.
PLEASE BE AWARE:
WARRANTY WILL BE NULL AND VOID IF PANEL
SURGE PROTECTION IS NOT INSTALLED WITH
ALL LCD MPPT INSTALLATIONS
