The display changes to: BATTERY PACK SELECT
8.6 Battery Set Voltage
This allows the MPPT to auto select the battery system or the
MPPT can be PRESET.
• AUTO
• 12 volt, 24volt, 36volt, 48 volt battery pack.
• Default Value is 12 – 48 AUTO SELECT.
➢ Press the <DATA> button to change the BATTERY PACK SELECT
➢ Press the <CHARGE> button to save the setting
The screen changes to: CHARGE LIMIT
8.7 Charge Limit
This allows the user to limit the MPPT current.
100 % will be 20 amps or if the limit must be 18 amps then set
the % to 90 % for a 20Amp MPPT as an example.
The charge limit can be set in 5% increments. 0% - 100%.
This can be extended to any LCD MPPT type accordingly.
Default Value is 95%.
➢ Press the <DATA> button to change the battery CHARGE LIMIT
➢ Press <CHARGE> to save the setting.
The screen changes to: EXTERNAL OUTPUT
8.8 External Output Connections:
Please refer to Section 9 : External Output Connections.
The screen changes to: SET OPERATION MODE
8.9 Set Operation Mode
MODE 0 is the Low Frequency Setting – 34MHz.
MODE 1 is the High Frequency Setting – 77MHz.
MODE 2 – 5 Is Currently Not Used.
• Default Value is MODE 0.
➢ Press the <DATA> button to change the OPERATION MODE
➢ Press the <CHARGE> button to save the setting
The screen changes to: SOLAR OR WIND
8.10 Solar or Wind Settings
This Setting allows the MPPT to be changed between a
solar MPPT and a Wind Turbine MPPT.
Please confirm that these settings are not adjusted as a
standard.
Confirm with support before adjusting these settings.
Default Value is SOLAR
➢ Press the <DATA> button to change the SOLAR OR WIND SETTINGS
