LCD MPPT SPECIFICATIONS
12. LCD MPPT SPECIFICATIONS
Recommended MPPT Sizes Per Array and Battery Set
Battery
Set
20 Amp MPPT
40 Amp MPPT
60 Amp MPPT
100 Amp MPPT
12V
250W
500W
750W
1300W
24V
500W
1000W
1500W
2500W
36V
750W
1500W
2200W
3600W
48V
1000W
2000W
3000W
5000W
Nominal Battery Voltage
Multi-Voltage (Automatic/Manual selection of
voltage - 12/24/36/48V battery set)
PV Input Voltage
Open Circuit Absolute Maximum 150VDC
Charge Algorithm
5-stage, 3-level Equalize/Boost/Float
Equalize Voltage
Charges12V to 15V per 12V DC battery pack for
1hour
Boost Voltage
13V – 16V per 12V Battery Pack
Float Voltage
12.4V – 14.5V per battery 12V Battery Pack
Power Conversion
DC/DC Switch Mode
Output Efficiency
Peak greater than 96% conversion efficiency
Voltage Step down Capability
Can charge a lower voltage battery from a higher
voltage PV array.
Status display
4 Line LCD Screen with Backlight
• Battery Voltage
• Charge mode-charge current
(Equalize/Boost/Float) and Charge current
• Panel Voltage
• Output Power
• State of charge of battery
Data Logger
• 24hr Average
• 63 day history
Power Consumption
Less than 1 Watt
Environmental Rating
0 – 40˚C
Protection System
Lightning Protection, Reverse polarity on
Panel/Battery
