Microcare LCD MPPT 20 - 7 Setup Menu Settings

28
SETUP MENU SETTINGS
FLOAT CHARGE VOLTAGE
=13.8V DEFAULT
BOOST TO FLT CHANGE
IF CHARGE < 6AMPS
BOOST TO FLT CHANGE
INTERVAL SCAN =10min
BOOST CHARGE VOLTAGE
=14.5V DEFAULT
EQUALISE CHARGE MODE
AUTO
ENABLED
BATTERY PACK SELECT
12 - 48V AUTO SELECT
CHARGE LIMIT IS @
= 95%
EXTERNAL OUTPUT IS A
UNUSED OUTPUT N/C
SET OPERATION MODE
F MODE 0
SOLAR OR WIND MPPT?
MODE = SOLAR
SET HOUR OF THE DAY
= 14:00
SET MIN OF THE HOUR
= 14:10
SET COMMUNICATIONS
ADDRESS =
7. SETUP MENU SETTINGS
Setup Menu - Quick Reference Guide
Menu Settings
12.4V – 14.5V
0.1V Increments
13.5V – 16V
0.1v Increments
Disabled, 10min, 30min,
1hr,2 hrs, Default = 10 min
Default = 1 Hr
3 - 6 – 15 – 30 Amps
Default is < 6 Amps
Auto or Manual select
Default is Manual
12 – 24 - 36- 48
Default is 12 – 48V Auto
Select
Adjustable in increments of
5%
Refer to Section 9
Mode 0 or Mode 1
Default=Mode 0
Solar or Wind
Default=Solar for PV Panels
Sets the hours in 1 hour
increments
Sets the minutes in 1 min
increments
Default=5 for the first MPPT
