The EasyPIC4 development system is a full-featured development board for
Microchip PIC microcontrollers. It has been designed to allow students and engi-
neers to easily exercise and explore the capabilities of PIC microcontrollers. It
allows PIC microcontrollers to be interfaced with external circuits and a broad range
of peripheral devices, allowing a user to concentrate on software development.
Figure 1 illustrates the development board. Each component is marked on a
silkscreen, both top and bottom. These marks describe connections to the microcon-
troller, operation modes, and provide some useful notes. The need for additional
schematics is minimized since all relevant information is printed on the board.
IINNTTRROODDUUCCTTIIOONN
INTRODUCTION
Figure 1.
EasyPIC4 development board
