1.0 Overview
1.2 Specifications
IPn3Gii
IPn3Gii Supported Bands: UMTS/HSPA FDD Bands [MHz] - Six band
Band I (2100MHz), Band II (1900MHz), Band IV (1700MHz), Band V
(850MHz), Band VI (800MHz), Band VIII (900Hz)
3GPP Release 7
5.76 Mb/s uplink, 21.1 Mb/s downlink
or 5.76 Mb/s uplink, 7.2 Mb/s downlink
IPn3Gii Data Features: HSDPA cat 14, up to 21.1 Mb/s DL
GPRS multi-slot class 125, coding scheme CS1-CS4, up to 85.6 kb/s DL/UL
EDGE multi-slot class 125, coding scheme MCS1-MCS9, up to 236.8 kb/s DL/UL
CSD GSM max 9.6 kb/s
UMTS max 64 kb/s
IPn3Gii TX Power: WCDMA/HSDPA/HSUPA Power Class
· Power Class 3 (24 dBm) for WCDMA/HSDPA/HSUPA mode
GSM/GPRS Power Class
· Power Class 4 (33 dBm) for GSM/E-GSM bands
· Power Class 1 (30 dBm) for DCS/PCS bands
EDGE Power Class
· Power Class E2 (27 dBm) for GSM/E-GSM bands
· Power Class E2 (26 dBm) for DCS/PCS bands
IPn4Gii
IPn4Gii Supported Bands: LTE FDD (Bands 1-5,7,8,13,17,18,19,20)
UMTS | DC-HSPA+ (Bands 1,2,4,5,8)
GSM | GPRS | EDGE (Bands 2,3,5,8)
3GPP Protocol Stack Release 9
IPn4Gii Data Features: LTE: DL 100 Mbps, UL 50 Mbps
HSPA+: DL 42 Mbps, UL 5.7 Mbps
HSPA+: DL 21 Mbps, UL 5.7 Mbps
WCDMA: DL/UL 384 kbps
EDGE Class 33: DL/UL 236.8 kbps
GPRS Class 33: DL/UL 85.6kbps
General
Serial Interface: RS232, RS485, RS422
Serial Baud Rate: 300bps to 921kbps
USB: USB 2.0
USB Console Port
USB to Serial Data Routing
USB to Ethernet Data Routing (NDIS)
USB OTG (Host)
Current Consumption:
(@12VDC)
Model
AVG Serial
Data
AVG Ethernet
Data
TX Max. Peak
IPn3Gii 130mA 140mA 215mA
IPn4Gii 130mA 145mA 250mA
