© Microhard 71
4.0 Configuration
Protocol
Select the type of transport protocol used. For example Telnet uses TCP,
SNMP uses UDP, etc.
Values (selection)
External Port
Port number of the incoming request (from WAN-side).
Single port or port ranged can be specified (start: stop)
Values (Port #)
2000
TCP / UDP / Both
Name
This is simply a field where a convenient reference or description is added
to the rule. Each Forward must have a unique rule name and can use up to
10 characters.
Values (10 chars)
Forward
Internal Server IP
Enter the IP address of the intended internal (i.e. on LAN side of the
pMDDL) server. This is the IP address of the device you are forwarding
traffic to.
Values (IP Address)
192.168.2.1
Internal Port
Target port number of the internal server on the LAN IP entered above.
Single port or port ranged can be specified (start: stop)
Values (Port #)
3000
Exception Port
Enter a exception port number that will NOT be forwarded to the DMZ
server IP. Usually a configuration or remote management port that is
excluded to retain external control of the pMDDL.
Up to 15 ports can be specified using list (port1, port2, etc) or by port range
(start: stop)
Values (Port #)
0
Firewall Port Forwarding Configuration
If the firewall is set to block
incoming traffic on the WAN
interface, additional rules or
IP/MAC lists must be
configured to allow desired
traffic access.
Source
Select the source for the traffic, if applicable.
Values (selection)
(none)
