LVS-95XX Series Barcode Quality Station Operations Manual
LVS-95XX Series Barcode Quality Station Operations Manual - English Page 17 of 94
LVS-9580 Hardware Specifications
Physical Properties
Height 8.5” 215.9 mm
Width 4.75” 120.6 mm
Depth 5.5” 139.7 mm
Weight Unpackaged Weight = 15.5 oz (.44 kg)
Shipping weight (includes all items
packaged in shipping box, such as cables,
manuals, etc.) = Approximately 4 pounds
(1.81 kg)
Imaging Device
• 5.0 mp camera
• Object Distance: Contact
Field of View
• 3.0” (76.19 mm) horizontally
• 2.25” (57.15 mm) vertically
Minimum Barcode X Dimension
• 1D = 4.0 mils (0.10 mm)
• 2D = 5.9 mils (0.15 mm)
Minimum PC Requirements (PC Supplied by
Customer)
• Windows® XP Professional or Windows® 7 (Windows®
Vista is not supported)
• Intel® Core™ 2 Duo Processor (or equivalent)
• 2 GB RAM
• 800 x 600 Resolution
• One available USB 2.0 port
Power Requirements
• USB Powered 5VDC @ 180mA
Light Source
• Red 660 nm filter
Communication
• USB 2.0 A/MINI-B cable 10 feet (3048 mm)
Operating and Storage Temperature
• 4º C (40º F) to 46º C (115º F)
Relative Humidity
• 5% to 95% (non-condensing)
Calibration
• EAN/UPC Calibrated Conformance Test Card
Safety Compliant
• RoHS/WEEE compliant
• CE
Q
Specifications and photos subject to change.
