LVS-95XX Series Barcode Quality Station Operations Manual
LVS-95XX Series Barcode Quality Station Operations Manual - English Page 18 of 94
LVS-9500 Hardware Specifications
Physical Properties
Height 18” 18 mm
Width 13” 330 mm
Depth 17” 432 mm
Weight 27.5 pounds 12.5 kg
Light Source
• White Light
• Red Filter
• 660 nm
Inputs / Outputs
• 3 USB ports
• 1 Serial port
• 1 External VGA port
• External USB mouse
• 10/100 LAN (Ethernet)
• 12 vdc @ 1 amp (nominal)
• 5 vdc @ 2.4 amps (nominal)
Main Power Supply
• Internal fuse (5A)
• 350 watt ATX power supply
• 50/60 hz 100 to 240 VAC
Monitor
• Built in, 12.1”
• 800 x 600 LCD Display
Video Camera
• Monochrome
• 2.1 or 1.3 Mega-pixel
Computer
• Intel-based processor
• 512 MB memory
• 40 GB hard drive (minimum)
• Windows XP Professional
• 12V @ 4.87 A5V @ 12.2 A
• Elastomer keyboard
Operating and Storage Temperature
• 0ºC (32ºF) to 40ºC (104ºF)
Relative Humidity
• 20% to 70% (non-condensing)
Calibration
One of the following:
• EAN/UPC Test Card
• GS1-128 Test Card
q
Specifications and photos subject to change.
