Midea MGBT-F30W/RN1 User Manual

MCAC-ATSM-2014-09 Aqua tempo power series tropical air-cooled scroll chiller 50Hz
67
No.
Part Name
Qty
No.
Part Name
Qty
27
Compressor installed base I weld
1
54
Roof rack beams II
1
28
Vertical beams in the frame
2
55
Top cover
4
29
I left panel
3
56
I beam roof rack
1
30
Evaporator inlet pipe ass'y of unit B2
1
57
Vertical beam roof rack
2
30.1
Electronic expansion valve
1
58
Total water temp. sensor ass'y
1
31
Inlet pipe ass'y of unit A2 evaporator
1
59
Wired controller
1
31.1
Electronic expansion valve to take over
1
60
Pipe temp. sensor ass'y
1
32
Input pipe ass'y of unit B1 evaporator
1
61
Pipe temp. sensor ass'y
4
32.1
Electronic expansion valve
1
62
Pipe temp. sensor ass'y
3
33
Input pipe ass'y of unit A1 evaporator
1
63
Pipe temp. sensor ass'y
1
33.1
Electronic expansion valve
1
64
Indoor temp. sensor ass'y T41
2
34
Four-way valve ass'y of unit B1
1
65
Pipe temp. sensor ass'y
2
34.1
Four-way valve set
1
66
Discharge temp. controller
4
34.3
Pressure controller
1
67
Electric heater of compressor
4
34.4
Meter connector
2
68
Refrigerant
26
35
Four-way valve ass'y of unit A1
1
69
Electronic expansion valve coil
4
